Assistant Service Manual
OPTIKON 2000
Code 121008S 2-3 Rev. D
PARAMETER SPECIFICATION
DIATH (DIATHERMY)
Type: ................................. bipolar generator - generator stops when RF
power is not needed
Operating frequency: .............. 2 MHz
Nominal power:..................... 7W (450 Ohm LOAD)
No load max. voltage: ............. 100 V
Default bipolar power: ............ user programmable
Available bipolar power: .......... 5 to 100% (percent)
Surgeon mode (linear power): ... allows linear control of the DIATHERMY power via
system footswitch depression
Handpiece type: .................... bipolar microforceps, slim stat pencil eraser,
intraocular diathermy pencils
Diathermy cable: ................... two poles, 26 gauges, 75 ohm, steam
autoclavable. Use only original OPTIKON 2000
S.P.A. diathermy cable
Control: .............................. system footswitch
ILLUM (ILLUMINATION)
Source type: ........................ dual independent HID lamps
Power: .............................. 35+35 watt
Intensity adjustment: ............. mechanical diaphragm, four levels + green filter
AIR INJECTION SECTION :
Nominal pressure: .................. from 5 to 80 mm/Hg
Actual IOP: .......................... Nominal pressure ± 3 mm/Hg
Safety devices: ..................... Air activation sound
SILICONE INJECTION SECTION :
Nominal pressure: ................. from 40 to 500 KPa (0.4 to 5 bar)
Signals: .............................. Silicone injection activation sound, Low pressure
at air inlet
PHACOEMULSIFIER
Handpiece type: .................... piezoelectric
Frequency: .......................... approx. 40KHz
Tip stroke: ........................... from 0 to 100µm
