Version 1.2.8 - 2020-08-03 19Translation of original operating manual
MT50 GB
MT50_GB_2.fm
2 Technical data
The following information are the dimensions and indications of weight and the manufacturer‘s
approved machine data.
2.1 Electrical connection
Total connected load 4.5 KW / 400V / 50Hz
Motor power horizontal spindle 1.5 kW
Motor power vertical spindle 1.1 / 2.2 kW
2.2 Dimensions
Spindle seat (horizontal milling, vertical milling) Taper SK 40
Cross table, model up to serial number
J201310355
800mm x 240mm
Cross table, model up to serial number
J201310356
1000mm x 240mm
Height
Installation plan on page 22Width
Depth
Total weight 900 kg
Weight including packaging 1050 kg
Dimensions of packaging L x W x H 1290 x 1220 x 2100mm
Max. load of cross table 160 kg
T-slot size / number 14mm / 4
2.3 Adjustment travels/ Slewing ranges/ Distances
Spindle stroke 120 mm
Traverse path X direction cross table 580 mm
Scaling travel X direction cross table 0.002mm
Traverse path Y direction cross table 200 mm
Scaling travel Y direction cross table 0.002mm
Traverse path Z direction cross table 340 mm
Scaling travel Z direction cross table 0.002mm
Throat vertical spindle 240 - 650 mm
Throat horizontal spindle 0 - 185 mm
Spindle stroke vertical spindle 0 - 120 mm
