EX765/EW766/EX765W/EW766W
Condential VII
ASSY LVPS MODULE EX765
Item P/N Description Parts Supply
1 42.00451G011 W.A. 16P 90mm LVPS TO MAIN BD UL1007 P1266
2 42.89602G001
CABLE W.A. 3P #20 180mm LAMP DRIVER TO
LAMP EP759
3 52.8BY04G001 LVPS ISOLATED SPONGE CR EX765
4 75.8BV02GP01 ASSY MATRITEK 280W LVPS .STAND-BY<1W V
5 75.8BY03G001
ASSY INTERRUPTER SWITCH (CORE) 280mm
EX765
5
4
1
3
2
