Optoma EX765 - 2-10 Disassemble Engine Module

EX765/EW766/EX765W/EW766W
Condential 2-19
5. Separate t�ermal switc� and fan �older.
Note: Please hold fan in the right way, the
same to blower.
2-10 Disassemble Engine
Module
1. Open 4 clips on t�e inside left and rig�t
of t�e lens s�ift cover (as red dotted
line) to take it off .
Note: When assembling the lens shift cover,
make sure the 4 clips are xed well.
Rotate the upper gear wheel to its left
end, then rotate the under gear wheel to
aim the graduation on the engine base
straight at that of the engine stand (as
red square).
↔
←
Lens shift cover
OK
