EX765/EW766/EX765W/EW766W
Condential
II
Item P/N Description
Parts
Supply
1 51.8BY10G001 LAMP COVER PC EX765 V
2 51.8BY16G001 ENGINE ANTI LIGHT MYLAR RIGHT
3 51.8BY17G001 ENGINE ANTI LIGHT MYLAR LEFT
4 51.8BY28G001 HEATSINK WIND GUIDE MYLAR EX765
5 51.8BY30G001 HEAT SINK LIGHT CUT MYLAR EX765
6 75.8BY07G001 BUY ASSY LENS SHIFT COVER MODULE EX765
7 85.005AGG075 SCREW HEX I/O #4-40*H5*L7.5 Ni NYLOK
8 85.1A123G050 SCREW PAN MECH M3*5 Ni
9 70.8BY01G001 ASSY BOTTOM HOUSING MODULE EX765
10 75.8BY17G001 BUY PRE-ASSY BACK COVER MODULE EX765 V
11 70.8BY29GR01 ASSY TOP COVER MODULE FOR EX765 (SERVICE) V
12 SP.8BY01GC01 LAMP MODULE FOR PROJECTOR EX765/EW766 V
13 70.8BY21G001 ASSY MAIN/IO BOARD MODULE EX765W
14 70.8BY24GR01 ASSY ENGINE MODULE FOR EX765(W) (SERVICE) V
