Repeat the previous steps to change the Frame Rate or the
Genlock source. In the example, a 30Hz frame rate was
selected.
►O/P Mode 2560x1600p
Frame Rate
I/O Lock Off
FR Enable
If the input source is a Mac computer and the unit is
connected to a non-HDCP display, you need to turn off HDCP
to receive non-protected content.
Display Type
Gamma/Color/Crush
►Output Config
Video Wall
Enter the HDCP menu from the Output Config menu and
select HDCP. Enter the menu to turn off HDCP. Immediately
HDCP will also be disabled on all the input channels.
DVI Output DVI forced
►HDCP Off
Color Space RGB
output is filled with the input image ignoring
any mismatch between the input and output aspect ratios.
To maintain the input source aspect ratio, select the Original
or Crop settings from the Geometry
►Original
Full Screen
Crop
Hit Esc several times and return to the status menu. In the
example, the menu indicates that a 4K source is connected to
HMDI-1, the output is set to 2560@30 and the unit is free
In: 3840x2160 60Hz
HDMI 1
Out:2560x1600p 30.00
Free Run
