optris CTlaser LT - Connector Version

Electrical Installation 57-
4.1.2 Connector version
Use the original ready-made, fitting connection cables which are optionally available.
Consider the pin assignment of the connector (see Figure 13).
This version has a connector plug integrated in the sensor backplane
Figure 12: Connector version
