optris CTlaser LT - Exchange of the Head Cable

-68 -
To enter the code press the Up and Down key (keep pressed) and then the Mod e key. The display shows
HCODE and then the 4 signs of the first block. With Up and Down each sign can be changed. Mode switches
to the next sign or next block.
Figure 21: Sensing head
4.6 Exchange of the head cable
To avoid influences on the accuracy use an exchange cable with the same wire profiles and
specification like the original one.
The sensing head cable can also be exchanged if necessary.
