Electrical Installation 75-
Hold Reset Low
Input digital
Reset of Peak or valley hold (High-Low signal)
Hold Reset High
Input digital
Reset of Peak or valley hold (Low-High signal)
Emissivity external
Input analog
The emissivity value can be adjusted via a 0-10 V signal on the
I/O pin (scaling possible via software).
Uncommitted value
Input analog
Display of a uncommitted value
Laser on Low
Input digital
Turning on the laser (Low signal)
Laser on High
Input digital
Turning on the laser (High signal)
External Ambient
Compensation
Input analog
The ambient temperature will be determined by a voltage on the
I/O-pin [0–10 V; range scalable].
External Transmitted
Radiation
Input analog
The transmitted ambient temperature will be determined by a
voltage on the I/O-pin [0–10 V; range scalable].
Low/High-level:
Via software
