Callout Description
5 FM 0 bi-color status LED:
• Fan OK: green
• Fan-Service Required: amber
• System Locate: all fan modules blink green to locate the system
6
High speed fan module 1 (FM 1)
7 FM 1 bi-color status LED:
• Fan OK: green
• Fan-Service Required: amber
• System Locate: all fan modules blink green to locate the system
8
High speed fan module 2 (FM 2)
9 FM 2 bi-color status LED:
• Fan OK: green
• Fan-Service Required: amber
• System Locate: all fan modules blink green to locate the system
10
Power supply (PS 1)
11 PS 1 status LEDs:
• AC OK LED: green
• Fault-Service Required LED: amber
12 AC power input connector (PS 1)
13 Power supply (PS 2)
14 PS 2 status LEDs:
• AC OK LED: green
• Fault-Service Required LED: amber
15 AC power input connector (PS 2)
16 Power supply (PS 3)
17 PS 3 status LEDs:
• AC OK LED: green
• Fault-Service Required LED: amber
18 AC power input connector (PS 3)
Preparing the Server for Component Replacement
This section describes safety considerations and provides prerequisite procedures and
information about replacing components in the server.
Before you can remove and install components that are inside the server, you must perform
the procedures in some or all of the following sections. For more information, see the
component replacement procedures in this guide.
Safety Precautions
For your protection, observe the following safety precautions when setting up your equipment:
• Follow all standard cautions, warnings, and instructions marked on the equipment and
described in the "Oracle Server Safety and Compliance Guide" and "Important Safety
Information for Oracle's Hardware Systems".
Chapter 5
Preparing the Server for Component Replacement
5-2
