Note:
For accurate component identification, see Illustrated Back Panel Components
Breakdown.
Each fan module has one bi-color status indicator (LED) located at the back of the system
chassis. If the fan is operating normally, the indicator is lit green. If the fan is faulty, the
indicator is lit amber.
Alternatively, to list all known faults in the server, log in to the ILOM service processor from
the ILOM Fault Management Shell and issue the
fmadm faulty
command. For more
information, refer to "Oracle ILOM User's Guide for System Monitoring and Diagnostics" in
the Oracle Integrated Lights Out Manager (ILOM) Documentation.
3. Prepare the system for fan module removal.
See Electrostatic Discharge Safety.
4. Gain access to the rear of the server where the faulty fan module is located.
5. Grasp the fan module handle and use your thumb to push the release latch inwards,
toward the handle [1]. Then pull the fan module straight out of the chassis [2].
Note:
If the release lever becomes stuck (it won't move all the way right to the released
position), push the lever down as you slide it in toward the module handle. This
will help prevent the lever from binding in its slot in the fan module sheet metal.
Chapter 5
Replacing a Fan Module
5-7
