Hardware Overviews
■
Max heat output: 6143 BTU/hr
■
Volt-Ampere rating: 1837 VA @ 240 VAC, 0.98 P.F.
ZS3-4 Configuration Options
The ZS3-4 controller can be configured as a single controller or two controllers to create a high-
availability cluster configuration. The following table describes the configuration options:
CPU Memory Readzilla SAS-2 Boot Drive SAS-2 HBA SAS-2
4x10-core, 2.40GHz 1TB (16GB DIMMs) Four 1.6TB Two 1.2 TB or
900GB
4-port (4X4) SAS-2
6Gb/s external
Refer to https://www.oracle.com/storage/nas/index.html for the most recent component
specification.
ZS3-4 Front Panel Components
FIGURE 19
ZS3-4 Front Panel
Installation Prerequisites and Hardware Overviews 35
