Hardware Overviews
■
Ethernet Ports - There are four RJ-45 Gigabit Ethernet ports (NET0, NET1, NET2, NET3)
located on the motherboard that operate at 10/100/1000 Mbit/sec. These network interfaces
must be configured before use.
■
Network Management Port - The network management connector (NET MGT) is an RJ-
45 port and provides an alternate terminal interface to the SP console.
■
Serial Management Port - The serial management connector (SER MGT) is an RJ-45 port
and provides a terminal connection to the SP console.
Installation Prerequisites and Hardware Overviews 55
