3600 Analyzer for O
2
Measurement—Operator’s Manual 59
3600O2.OM.E9903
2.2.5 Model 28117 External Pressure Sensor Installation
The model 28117 external pressure sensor has a 4-pin LEMO connector which
plugs into the socket labeled “pressure” on the instrument rear panel. This
pressure sensor can be mounted in the model 32002.x flow chamber, as shown in
section 2.2.4 above. It is held in place by a threaded, blue-colored aluminum collar.
Maximum cable length is 50 meters.
