IV Ocean TRx™ 4500 Installation and Operations Manual
Safety Precautions
The following general precautions apply to the installation, operation and servicing of
the system. Specific warnings appear throughout the manual where they apply and
may not appear in this summary.
Only qualified and trained personnel should perform installation,
operation and maintenance of this equipment.
Only certified electricians should perform installation procedures that
relate to the electrical system and its connections. All electrical work
must be performed in accordance with the relevant standards and the
instructions in this manual.
Before entering the Radome for maintenance purposes, shut off the main
power to the system from the ship’s electrical panel. Upon entry, switch
off the ADE power box.
Take extra care when handling the ADE power box, Slip-Ring, and power
supply units and their respective cables – which may be carrying 115/230
VAC.
Take extra care when handling the servo drivers – which are connected
to 48 VDC.
The system conducts potentially harmful voltages when connected to the
designated power sources. Never remove equipment covers except for
maintenance or internal adjustments.
Keep clear of the moving antenna at all times. The antenna pedestal is
equipped with high-torque motors that generate considerable force.
When units are connected to the chassis’s ground (to prevent shock and
similar hazards), the chassis’s ground conductor must not be removed.
To prevent shock or other hazards when sub-units are open or cables are
disconnected, do not expose the equipment to rain or moisture.
Avoid making unauthorized modifications to the system. Any such
changes to the system will void the warranty.
Do not disconnect cables from the equipment while the system is
running.
When not assembled, ensure that the system and its components are not
exposed to moisture or high humidity.
When installing the system, ensure to use the materials and tools
recommended in this manual.
NOTE: System interfaces require high-quality connectors and cables. Use only Orbit-authorized
parts for repair.
