Unpacking the System Unpacking and Mounting
4-2 Ocean TRx™ 4500 Installation and Operations Manual
ATTENTION!! Two people are required for the ADE unpacking and mounting
procedures.
(In most cases), the following procedures are the responsibility of the shipyard:
 Preparing for the attachment of Orbit’s Base Ring to the Radome support
 Installing the ADE/BDE cables and wiring
 Installing and connecting the modem.
NOTE: The remaining installation process is the responsibility of Orbit’s authorized technicians
4.1 Unpacking the System
NOTE: It is recommended to save the packaging. Use only the original packaging when transporting
the OceanTRx
TM
4-500 system from one location to another. Any other packaging may cause damage
to the system, and will not be covered by the warranty.
4.1.1 Crate Dimensions
The OceanTRx
TM
4-500 system is packed in a single wooden crate with the following
dimensions:
 Length: 1.91m (75.2”)
 Width: 1.91m (75.2”)
 Height: 1.98m (78”)
1.
Wooden Platform
2.
Cardboard
Sleeve
3.
Box Cover
4.
Radome
Figure 4-7: Shipping Crate
