Technical Data
OPEN-M OPEN-XL OPEN-XLi
Part Number 2SMPM6690/0C 2SMPM6334/0C 2SMPM6807/0C
CPU Celeron M 2 GHz
Intel Core 2 Duo
2,26 GHz
Intel Core™ i5-3610ME,
Dual Core, 2.7 GHz
Storage Compact Flash 1 - 4 GB/SSD - 128 GB
RAM 4 GB
Monitor port
1xVGA + 1x DVI-I
(independent display using dual O.S.)
Dual VGA or VGA/DVI
(independent display
using dual O.S.)
Ethernet 2x 10/100/1000 MHz
USB 6 x USB 2.0
4 x USB 3.0
2 x USB2.0
PS/2 2x (keyboard and mouse) -
Serial Line 3x RS232 - 1x RS232/422/485
5 x RS232
1 x RS232/422/485
Parallel port 1 x LPT1 -
Expansion Slot 2 x PCI 32 bit / 33 MHz
Power Supply 24Vdc
Power Consumption 2.5A @ 24Vdc
Housing Aluminum chassis
Operating system Single OS (Windows CE 6.0) / Dual OS (Windows CE 6.0 + WES7 64 bit)
Controlled axes Up to 32 Up to 64
Number of Processes Up to 4 Up to 24
Primary Fieldbus
Mechatrolink III, Mechatrolink I/II, EtherCAT
(SoE and CoE proles), OS-Wire
Secondary Fieldbus EtherCAT, CANopen, Probus
The following resources are available on the axes board
Board P/N 1SMPC6912/0C
(OS2021)
93000807P
(OS2005)
1SMPC6911/0
(OS2021)
93000808A
(OS2005)
Primary
eldbus
Mechatrolink III
Mechatrolink I
or II
EtherCAT OS-Wire
Secondary
eldbus
EtherCAT
CANopen
EtherCAT
CANopen
Probus
CANopen
EtherCAT
CANopen
Probus
Analog Axis 1 x 16 bit Analog Out + 1 x Inc. Encoder Input
Analog In. 2 x 12 bit ±10V (or 4-20 mA on channel one)
Fast In. 4 (or 3 + Touch-Probe)
Fast Out. 3
Power
enabling
1 (fast out 24V)
