OPENconsole COMPACT 15”
Also called “All-In-One”, this is the Operator
Panel for the entire OPENcontrol CNC
range which optimises features, prices, and
dimensions without sacricing design and
ease of use.
15” Monitor (1024 x 768)
Single, light, flat, panel mounting
frame
Complete and customizable Control
Panel
Customizable Control Panel extension
Emergency Stop push button
2 general purpose mechanical push buttons
Standard QWERTY “Bubble keys” keyboards with metal “snaps”.
USB port
Touch pad
Touch Screen
The Control Panel section includes all the commands needed for complete OPENcontrol
CNC management (mode selection, cycle start/stop, reset, feed rate, speed rate). It
is fully customizable as well as the Control Panel extension including 6 keys, with LED,
congurable by means of custom graphics and specic PLC management.
OPENcontrol Technical overview
43
