Technical Data
OPENrio SL
Bus coupler 8SMPM053-1EC00
Fieldbus EtherCAT
N° of managed modules Up to 64
Assembly DIN rail mounting - modules connected by side contacts
Dimensions (W x H x D) 12,9 x 109 x 76,5 mm
I/O signals insulation Electrical isolation
Operating Temperature 0°C...+60°C
Relative humidity 10 to 95% no condensation
Digital modules 8SMPM021-1BF00 8SMPM022-1BF00
Number of I/O 8 Input 8 Output
Current for each output - 0,5A (max 4 A per module)
Power output modules 8SMPM022-1BD20 8SMPM022-1HB10
Number of I/O 4 Output 2 Relay Output
Current for each output 2A (max 4A per module) 3A
30 VDC / 230 VAC
Analog modules 8SMPM031-1BB40 8SMPM031-1BB70 8SMPM031-1BD70 8SMPM032-1BB70
Number of Input 2 Input 2 Input 4 Input 2 Output
Input/Output eld 0/4….20mA ±10VDC ±10VDC ±10VDC
Resolution 12 bit
Temperature Sensor Pt/Ni 8SMPM031-1BD80
Number of Input 4 Analog Input
Resolution 16 bit
Temperature sensors Pt100/Pt1000 – Ni100/ Ni1000
PWM Module 8SMPM022-1BB90
Number of Output 2 Output
Current for each output 0,5A
Switching frequency Max. 40 kHz
Encoder Input Module 8SMPM050-1BA10
Maximum input frequency 500 kHz
Auxiliaty Power Module 8SMPM007-1AB00
Supported current 10A
