Technical Data
OPENrio E901 including EtherCAT Bus Coupler
P/N 2SMPM5993/0C and 2SMPM6293/0C
Fieldbus EtherCAT
Assembly DIN rail mounting
Operating Temperature 0°C...+50°C
Relative humidity 90% no condensation
Digital Input
Number of Input 4
Current for each input >= 5 mA
Digital Output
Number of Output 4 (2 congurable as PWM outputs)
Current for each output 100 mA
PWM
Frequency and duty cycle programmable.
Max frequency 10KHz. Up to 50 KHz depending on duty cycle.
Analog Output
Number of I/O 1
Output range 0÷10 V
Resolution 14 bit plus sign
Protection Short circuit
Bandwith 20 KHz
Analog Input
Number of I/O 1
Input range 0 ÷10 V
Resolution 14 bit plus sign
Bandwith 20 KHz
