102
MAIN---------------------------------
9:57:32 A
SUM STATUS SETUP ADV
STATUS--------------------------------
choose device:
FX CC DC MATE
STATUS/FX/PG1 ----------------P01
choose category:
MODES METER BATT PG2
STATUS/FX/BATT--------------P01
battery 25.0 vdc
actual
DOWN STATUS PORT
e top line of the MATE display will show
the ‘path’ to the current menu; in this example
it is STATUS/FX/BATT--------P01 with “P01”
referring to the rst port of the HUB.
