52
AC INPUT CONTROL
currently: DROP-HBX
DROP USE OK
AC INPUT CONTROL
currently: USE-HBX
DROP USE OK
or
• e AC INPUT CONTROL screen is
called up, allowing the user to connect or
disconnect the FX to an AC input source.
• If a HUB is employed, AC INPUT
CONTROL only aects the Master FX
connected to PORT 1; the Master FX then
gives the same command to the Slave FXs
AC INPUT CONTROL
currently: USE
DROP USE OK
<USE> enables the FX to connect to an AC input source.
<DROP> disconnects the AC input source but will allow it to be reconnected if the “low
battery cut-o set point” occurs or the FX is overloaded.
<OK> returns to the point in the menu system before you entered the AC INPUT CONTROL
menu cycle.
If HBX Mode is enabled, the AC INPUT CONTROL will read:
PRESS ONCE:
INV
Hot
AC IN Hot Key
e AC IN “hot” key allows direct control of the AC input from anywhere in the menu system.
e yellow LED indicator above the AC IN “hot” key has three settings:
u Flashing - an AC source is available, but not connected
u Continuously On - the AC source is connected and in use
u O - no AC source is present
e number of AC IN key presses determines which menu is called up.
MAIN--------------------------
1:35:04p
SUM STATUS SETUP ADV
