Outback MATE User Manual

118
ADV/MATE/AGS/TIMERS--
agsstate 0
DOWN AGS
ADV/MATE/AGS/TIMERS--
genfault 0
DOWN UP
ADV/MATE/AGS/TIMERS--
24 hr 1440 min
vs time
DOWN UP
ADV/MATE/AGS/TIMERS--
2 hr vs time 120 min
DOWN UP
ADV/MATE/AGS/TIMERS--
2 min 2 min
vs time
DOWN UP
ADV/MATE/AGS/TIMERS-
lsstart timer 0 min
DOWN UP
ADV/MATE/AGS/TIMERS-
lsstop timer 0 min
DOWN UP
ADV/MATE/AGS/TIERS-
exstop timer 0 min
DOWN UP
ADV/MATE/AGS/TIMERS
end of TIMERS
menu
UP TOP AGS
ADV/MATE/AGS/PG2----
Choose category:
QUIET VOLT
SETUP TIME START P2
ADV/MATE/AGS--------
Choose category:
LOAD MUST
P2 START RUN P3
MAIN----------------
6:54:42P
SUM STATUS SETUP ADV
ADV/SETTINGS/WARNING
changes made could
adversely eect
system performance
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
ADV-----------------
choose device:
FX CC DC MATE
ADV/MATE/PG1
choose category:
HBX GRIDUSE AGS P2
ADV/MATE/AGS/EX-----
exstart day --
DOWN AGS INC DEC
ADV/MATE/AGS/EX-----
ex start time 12:00A
DOWN UP CHANGE
ADV/MATE/AGS/EX-----
ex period 15 min
DOWN AGS INC DEC
EXERCISE
ADV/MATE/AGS--------
Choose category:
%SOC
P2 START TIMERS P4
ADV/MATE/AGS/PG4----
choose category:
P3 EXERCISE ADV
ADV/MATE/AGS/EX-----
end of
exercise menu
UP TOP AGS

Outback MATE Specifications

General

Display	LCD
Operating Temperature Range	-20°C to 60°C
Mounting	Wall Mount
Type	System Display and Controller
Communication	RS232
Communication Ports	RS232
