MAIN--------------------------------
12:00:30P
SUM STATUS SETUP ADV
If the MATE has a FLEXnet DC connected to it,
an initial FLEXnet DC screen will be displayed
as the Summary default screen.
Pressing the second so key brings up the next
three FLEXnet DC summary screens as well as the
FX and Charge Controller summary screens.
Summary Screens
e Summary screens provided by the MATE:
• Summarize the current status of any FX, OutBack Charge Controller and/or FLEXnet DC
connected to it.
• Can be accessed from the <MAIN> screen by pressing the <SUM> so key and can be set
to pop up like a screen saver aer a delay (See Summary Screen Options on the next page
for more setup information).
Any MATE so key pressed while the Summary screen is being displayed returns you to the
screen that was active before the Summary screen was displayed. Pressing the two lower le
so keys at the same time opens the MAIN Menu screen.
E F
Battery Discharging
State of Charge 100%
DC Now 25.4V 100%
In 0.1A 0.000 kW
Out 0.4A 0.010kW
Bat -0.3A 0.010kW
DC TODAY minSOC 97%
In 102AH 2.70 kWH
Out 93AH 2.44kWH
Bat 9AH 0.26kWH
DC BAT 25.4V 100%
Bat -0.3A -0.010kW
Net 0AH 0.00kWH
Days Since Full
1.1
e FLEXnet DC summary screens display
the battery state of charge, including the day’s
minimum, the current DC voltage, and the in
and out kilowatt hours and amp hours.
