56
NOTE: For a global charger command to work, all of the OutBack products must be connected
to a HUB. e CHARGER MODE CONTROL aects both FX Series Inverters/Chargers
and OutBack Charge Controllers. is requires that the FX and OutBack Charge Controller
rmware versions support this feature (See page 124, Troubleshooting, if this command fails to
function).
To stop an equalizing process, return to the EQUALIZE CONTROL screen and press the
<STOP> so key. To return to the EQUALIZE CONTROL screen:
• Press the <AC IN> hot key four times.
• Press the <EQ> so key.
• Press the <STOP> so key on the EQUALIZE CONTROL screen.
AC INPUT CONTROL
Hot Key
CHARGER MODE CONTROL
Global charger mode
BULK EQ OK
EQUALIZE CONTROL
eq enabled Yes
START STOP OK
MAIN--------------------------
1:35:04p
SUM STATUS SETUP ADV
