MATE ADVANCED Default Values
ADV/MATE/HBX--------------------
hbx-use 12.0 vdc
grid setpoint
DOWN ADV INC DEC
ADV/MATE/HBX--------------------
hbx-drop 13.0 vdc
grid setpoint
DOWN ADV INC DEC
ADV/MATE/HBX--------------------
hbx-use 01.0 hrs
grid delay
DOWN ADV INC DEC
ADV/MATE/HBX---------------------
hbx-drop 01.0 hrs
grid delay
DOWN ADV INC DEC
• Griduse Menu
ADV/MATE/GRIDUSE-----
griduse enable: OFF
DOWN ADV OFF ON
ADV/MATE/GRIDUSE-----
weekday 12:00A
griduse stop time
DOWN UP CHANGE
ADV/MATE/GRIDUSE-----
weekday 12:00A
griduse start time
DOWN UP CHANGE
ADV/MATE/GRIDUSE-----
weekend 12:00A
griduse start time
DOWN UP CHANGE
ADV/MATE/GRIDUSE-----
weekend 12:00A
griduse stop time
DOWN UP CHANGE
• HBX Menu
NOTE: e MATE’s hbx-use grid setpoint screen vdc value will
equal the battery voltage of the system it’s connected to. In
this case, it reects 12 VDC batteries.
NOTE: For a 24 VDC battery, the hbx-drop grid setpoint is
26.0 vdc; for 32 VDC, the value is 34.7 for 36 VDC, it’s 39.0
vdc; and for 48 VDC, the value will be 52 vdc.
• AGS SETUP Menu
MATE/AGS/SETUP------------------
ags port: 0
DOWN AGS INC DEC
ADV/MATE/AGS/SETUP------------
AGS control: MAN-OFF
DOWN UP CHANGE
ADV/MATE/AGS/SETUP------------
AGS enabled: No
DOWN UP NO YES
ADV/MATE/AGS/SETUP--------------
dc genset:: No
DOWN UP NO YES
ADV/MATE/AGS/SETUP-------------
ags fault 17 min
time
DOWN UP INC DEC
ADV/MATE/AGS/SETUP------------
vdc genstop 19.0 vdc
DOWN UP INC DEC
ADV/MATE/AGS/SETUP-------------
warm up time 0
minutes
DOWN UP INC DEC
ADV/MATE/AGS/SETUP------------
cool down time 0
minutes
DOWN UP INC DEC

Outback MATE Specifications

General

Display	LCD
Operating Temperature Range	-20°C to 60°C
Mounting	Wall Mount
Type	System Display and Controller
Communication	RS232
Communication Ports	RS232
