Outback MATE User Manual

99
ADV/MATE/AGS/MR----------------
weekday 12:00A
must run start time
DOWN AGS CHANGE
ADV/MATE/AGS/MR----------------
weekend 12:00A
must run start time
DOWN UP CHANGE
ADV/MATE/AGS/MR----------------
weekday 12:00A
must run stop time
DOWN UP CHANGE
ADV/MATE/AGS/MR-----------------
weekend 12:00A
must run stop time
DOWN UP CHANGE
• AGS MUST RUN Menu
ADV/MATE/AGS/EX-----------------
exstartday ----
DOWN AGS INC DEC
ADV/MATE/AGS/EX-----------------
ex period 15 min
DOWN UP INC DEC
ADV/MATE/AGS/EX-----------------
ex start time 12:00A
DOWN UP CHANGE
• AGS EXERCISE Menu
ADV/MATE/AGS/TIMERS
agsstate 0
DOWN AGS
ADV/MATE/AGS/TIMERS
24hr 1440 min
vs time
DOWN UP
ADV/MATE/AGS/TIMERS
agsgenfault 0
DOWN UP
• AGS TIMERS Menu
ADV/MATE/AGS/TIMERS
24hr vs time 120 min
DOWN UP
ADV/MATE/AGS/TIMERS
1sstart timer 0 min
DOWN UP
ADV/MATE/AGS/TIMERS
2 min 2 min
vs time
DOWN UP
ADV/MATE/AGS/TIMERS
1sstop timer 0 min
DOWN AGS
ADV/MATE/AGS/TIMERS
exstop timer 0 min
DOWN UP
ADV/MATE/AGS/TIMERS
vdcstop timer 0 min
DOWN UP

Outback MATE Specifications

General

Display	LCD
Operating Temperature Range	-20°C to 60°C
Mounting	Wall Mount
Type	System Display and Controller
Communication	RS232
Communication Ports	RS232
