FlashBack-4
User Guide
2.3 i-Conex Peripherals
In addition to the i-Conex cables supplied, a range of i-Conex peripherals are available from
Ovation Systems. A selection is shown below, please contact sales@ovation.co.uk for the
latest information.
Figure 5: Example i-Conex Peripherals
IC1A-5682: Mini Wide-Beam PIR Detector:
IC1A-5680: Mini Narrow-Beam PIR Detector:
500mm
500mm
Mini PIR
Detector with
mounting bracket
Mini PIR
Detector with
mounting bracket
5m
5M Male to Female
Extension
IC1C-5652: Long Extension 5.0 metres:
Miniature Low-Light
Colour Bullet Camera
Colour
with rapid deployment
clip mount
Micro-Cam
PAL/NTSC, 1/3" Sony Super HAD CCD II, 550 TVL, 0.05 Lux, 3.6 mm lense (changeable), 12V DC at 65mA
11 x 12 x 12mm
IC1A-5659 (PAL) / IC1A-5661(NTSC) : Bullet Camera:
55 mm
19 mm
IC1A-5662 (PAL) / IC1A-5663 (NTSC) : Square Camera:
IC1A-5781 (PAL) / IC1A-5782 (NTSC) : Micro-Cam:
Miniature Low-Light
Colour Square Camera
PAL/NTSC, 1/3" Sony Super HAD CCD II, 550 TVL, 0.05 Lux, 3.6 mm lense (changeable), 12V DC at 65mA
PAL/NTSC, 450 TVL, 0.008 Lux, 5V DC at 70 mA.
28 mm
25 x 25 mm
