Owon 4-CH VDS6000 Series User Manual

６０
Channel Isolation
100 : 1 @ 50Hz; 40 : 1 @ 10MHz
Time Delay Between
Channel (typical)
150 ps
Horizontal
System
Sampling Rate
VDS6074
VDS6104
4-CH
working
0.5 Sa/s - 250 MSa/s
2-CH
working
0.5 Sa/s - 500 MSa/s
1-CH
working
0.5 Sa/s - 1 GSa/s
VDS6074A
VDS6104A
4-CH
working
8-bit mode
0.5 Sa/s - 250 MSa/s
12-bit mode
0.5 Sa/s - 125 MSa/s
14-bit mode
0.5 Sa/s - 125 MSa/s
2-CH
working
8-bit mode
0.5 Sa/s - 500 MSa/s
12-bit mode
0.5 Sa/s - 250 MSa/s
14-bit mode
0.5 Sa/s - 125 MSa/s
1-CH
working
8-bit mode
0.5 Sa/s - 1 GSa/s
12-bit mode
0.5 Sa/s - 500 MSa/s
14-bit mode
0.5 Sa/s - 125 MSa/s
Interpolation
sin (x)/x
Record Length
10M
Scanning Speed (s/div)
1 ns/div - 100 s/div, step by 1 - 2 - 5
Sampling Rate / Relay
Time Accuracy
±25ppm (typical, Ta = +25℃)
Interval (△ T) Accuracy
(DC - 100MHz)
Single: ±(1 interval time + 25ppm x reading + 0.6ns);
Average>16: ±(1 interval time + 25ppm x reading + 0.4ns)
Vertical
System
Sensitivity
2 mV/div - 5 V/div
Displacement
± 2 V (2 mV/div - 50 mV/div)
± 20 V (100 mV/div - 500 mV/div)
± 40 V (1 V/div - 5 V/div)
Analog Bandwidth
100 MHz
Low Frequency
(AC coupling, -3dB)
≥10 Hz (at BNC)
Rise Time
(at BNC, typical)
≤ 3.5 ns
DC Accuracy
VDS6074
VDS6104
±3% when ≥ 2mV
VDS6074A
VDS6104A
±2% when ≥ 2mV
