Owon 4-CH VDS6000 Series User Manual

６１
DC Accuracy (average)
the voltage difference of any 2 points from the captured
signal, after taking the average from ≥16 captured signals
(△ V): ±(2% rdg + 0.05 div)
waveform inverted ON / OFF
Measurement
Cursor
Measurement
△ V / △ T / (△ V and △ T) between Cursor 1 and Cursor 2,
auto cursor
Automatic
Measurement
Vpp, Vmax, Vmin, Vtop, Vbase, Vamp, Vavg, Vrms, Overshoot,
Preshoot, Frequency, Period, Rise Time, Fall Time,
Delay A→B , Delay A→B , +Width, -Width, +Duty, -Duty
Lissajous Figure
Bandwidth
full bandwidth
Phase Difference
±3 degrees
Communication
Interface
USB device (type-C), USB host (Wi-Fi extension supported), LAN
Wi-Fi module available in option
Frequency
Counter
supported
Trigger
Trigger Level Range
Internal
±5 divisions from the screen center
Trigger Level
Accuracy (typical)
(working for signal with rise
time / fall time ≥ 20ns )
Internal
±0.3 division
Trigger
Displacement
changing according to different record length and time base
Trigger Hold-off
Range
100ns - 10s
Edge Trigger
Slope
rising, falling
Pulse Trigger
Trigger Condition
positive pulse: >, <, =
negative pulse: >, <, =
Pulse Width
Range
30ns - 10s
Video Trigger
Modulation
supported standard: NTSC, PAL and SECAM broadcast
systems
Line Number
Range
NTSC: 1 - 525;
PAL / SECAM: 1 - 625
Slope Trigger
Trigger Condition
positive pulse: >, <, =
negative pulse: >, <, =
Time Setting
30ns - 10s
