(1) Press the Mode function key, press the NexePage softkey,then press the
PM softkey to enter FSK user interface.
(2) Select carrier wave shape:
The carrier wave can be Sine, Square, Ramp, or Arbitrary wave (except
DC). Press , , , or to select a desired carrier wave
shap.
(3) Set carrier wave parameters:
Press the wave shap key of the selected carrier wave to display the
waveform and parameters of the carrier wave. You can change the
parameters of the carrier wave. Press Mode to return to the modulation
mode interface.
(4) Press the Rate softkey to set the FSK rate. The rate at which the output
frequency shifts between the carrier frequency and the hop frequency is
determined by FSK rate. The range is 2 mHz – 1 MHz.
(5) Set hop frequency:
Press the Hop Frequency softkey to set the hop frequency. The carrier
wave frequency shifts to the hop frequency with the specified FSK rate,
and then returns to the original frequency.
Utility Function Setting
Press the front panel Utility function key to enter the utility menu. You can set
the parameters of the generator such as: display settings, CH1/2 settings, and
system settings. Press Utility again to exit the utility menu.
Display Settings
Brightness Control
(1) Press the front panel Utility function key, press the Display softkey.
(2) Press the Backlight softkey to select Backlight.
(3) Turn the knob to adjust the value on the current cursor, use the /
direction key to move cursor left or right, or use the numeric keypad to
enter the parameter and then select % as unit. The range is from 0% to
100%.
Screen Saver
If there is no operation within the set screen saver time, the screen enters the
protection mode (minimize screen brightness to protect the screen and save
energy). Press any key (except the power button) to restore the brightness
before entering the screen saver.
