Owon DGE2000 Series User Manual

7.Specification
40
Phase noise
Typical (0dBm, 10kHz offset)
10MHz: ≤-110dBc/Hz
Square
Rise/fall time
< 20ns
Jitter (rms), typical (1Vpp,
50Ω)
200ps + 30ppm
Overshoot
< 5%
Ramp
Linearity
< 1% of peak output
(typical 1 kHz, 1 Vpp, symmetry 50%)
Symmetry
0% to 100%
Pulse
Period
DGE2035
67 ns to 500 s
DGE2070
50 ns to 500 s
Pulse Width
≥ 24ns
Rise and fall time
≥ 15ns
Overshoot
< 5%
Jitter (rms), typical (1Vpp,
50Ω)
200ps + 30ppm
Noise
Types
Gaussian white noise
Bandwidth (-3dB)
20 M
Arbiratry wave
Bandwidth
10M
Waveform length
2 to 8K points
Sampling rate
DGE2035
125Ma/s
DGE2070
300Ma/s
Amplitude accuracy
14 bits
Modulation Characteristics
Modulation Characteristics
Modulation Type
AM, FM, PM, FSK
AM
Carrier
Sine wave, square wave, ramp wave, arbitrary wave (except
DC)
Modulated signal
source
Internal
Internal modulation
waveform
Sine wave, square wave, ramp wave, white noise
Internal amplitude
modulation frequency
2 mHz to 100 kHz
Depth
0.0% to 100.0%
FM
