Owon DGE2000 Series User Manual

7.Specification
39
Frequency stability
±30 ppm at 0±40℃
Frequency aging
rate
±30 ppm per year
Amplitude Characteristics
Amplitude Characteristics (not specifically labeled, the load defaults to 50Ω)
Output amplitude
DGE2035
2mVpp ~ 20Vpp（≤ 10MHz）High Z
2mVpp ~ 10Vpp（≤ 35MHz）High Z
1mVpp ~ 10Vpp（≤ 10MHz）50 Ω
1mVpp ~ 5Vpp（≤ 35MHz）50 Ω
DGE2070
2mVpp ~ 20Vpp（≤ 10MHz）High Z
2mVpp ~ 10Vpp（≤ 70MHz）High Z
1mVpp ~ 10Vpp（≤ 10MHz）50 Ω
1mVpp ~ 5Vpp（≤ 70MHz）50 Ω
Amplitude accuracy
± (1% of setting + 1 mVpp) (Typical 1kHz sine, 0V offset)
Amplitude resolution
1mVpp or 4 digits
DC offset range
(AC +DC)
DGE2035
±(10 Vpk–Amplitude Vpp/2) High Z（≤ 10MHz）
±(5Vpk - Amplitude Vpp/2) High Z（≤ 35MHz）
±(5 Vpk – Amplitude Vpp/2) 50Ω（≤ 10MHz）
±(2.5 Vpk – Amplitude Vpp/2) 50Ω（≤ 35MHz）
DGE2070
±(10Vpk – Amplitude Vpp/2) High Z（≤ 10MHz）
±(5Vpk–Amplitude Vpp/2) High Z（≤ 70MHz）
±(5 Vpk - Amplitude Vpp/2) 50Ω（≤ 10MHz）
±(2.5 Vpk– Amplitude Vpp/2) 50Ω（≤ 70MHz）
DC offset accuracy
± (1 % of |setting| + 1 mV + amplitude Vpp * 0.5%)
Offset resolution
1 mVpp or 4 digits
Output Impedance
50Ω (Typical)
Signal Characteristics
Signal Characteristics
Sine
Bandwidth flatness (relative
to 1 kHz Sine wave, 1 Vpp)
≤10MHz: ±0.2dB
≤35MHz: ±0.3dB
≤70MHz: ±0.8dB
Harmonic distortion
Typical (0dBm)
DC to 1MHz: <-65dBc
1MHz to 35MHz: <-60dBc
35MHz to 60MHz: <-50dBc
Total harmonic distortion
< 0.2 %, 10 Hz to 20 kHz, 1 Vpp
Non-harmonic distortion
Typical (0dBm)
≤10MHz: <-70dBc
>10MHz: <-70dBc + 6dB/ sound interval
