SECTION 4 OPERATION
42
4.5.1.1 PROGRAM EXAMPLE
The following is an example of creating and executing a 3 phase, 108/187 volt, 400 Hz program.
From any metering display press the PROGRAM key.
PROGRAM: #1 FORM=3 COUPLING=DIRECT
FREQ=60 Va=120 Vb=120 Vc=120
WFa=1 WFb=1 WFc=1
#SEGS=0 Ilim=50 PHb=120° PHc=240°
Press 4, ENTER, to display Program 4.
Press EDIT, to edit program #4.
PROGRAM: #4 FORM=3 COUPLING=DIRECT
FREQ=60 Va=120 Vb=120 Vc=120
WFa=1 WFb=1 WFc=1
#SEGS=0 Ilim=50 PHb=120° PHc=240°
Press 3, ENTER, to select 3 phase form.
PROGRAM: #4 FORM=3 COUPLING=DIRECT
FREQ=60 Va=120 Vb=120 Vc=120
WFa=1 WFb=1 WFc=1
#SEGS=0 Ilim=50 PHb=120° PHc=240°
Press ENTER, to select DIRECT coupling. If XFMR is shown press +/-, then ENTER.
PROGRAM: #4 FORM=3 COUPLING=DIRECT
FREQ=60 Va=120 Vb=120 Vc=120
WFa=1 WFb=1 WFc=1
#SEGS=0 Ilim=50 PHb=120° PHc=240°
Press 400, ENTER, to select 400 Hz.
PROGRAM: #4 FORM=3 COUPLING=DIRECT
FREQ=400 Va=120 Vb=120 Vc=120
WFa=1 WFb=1 WFc=1
#SEGS=0 Ilim=50 PHb=120° PHc=240°
