4.5.2.1 TIME BASED TRANSIENT EXAMPLE (continued)
We are now starting segment 3 of 3.
TRANSIENT: PRGM #4 SEGMENT #3 OF 3
T=0.01 Va=108 Vb=108 Vc=108
F=400 WFa=1 WFb=1 WFc=1
Press ENTER, ENTER, .07, ENTER, to select default segment 3 of 3 and a time of .07 seconds (70 mSec).
TRANSIENT: PRGM #4 SEGMENT #3 OF 3
T=.07 Va=108 Vb=108 Vc=108
F=400 WFa=1 WFb=1 WFc=1
Press 108, ENTER, 108, ENTER, 108, ENTER, to select 108 volts on all three phases.
TRANSIENT: PRGM #4 SEGMENT #3 OF 3
T=0.07 Va=108 Vb=108 Vc=108
F=400 WFa=1 WFb=1 WFc=1
Press 400, ENTER, to select 400 Hz..
TRANSIENT: PRGM #4 SEGMENT #3 OF 3
T=0.07 Va=108 Vb=108 Vc=108
F=400 WFa=1 WFb=1 WFc=1
Press 1, ENTER, 1, ENTER, 1, to select WaveForm 1 on all three phases.
TRANSIENT: PRGM #4 SEGMENT #3 OF 3
T=0.07 Va=108 Vb=108 Vc=108
F=400 WFa=1 WFb=1 WFc=1
Press STORE, to save the transient sequence.
