SECTION 5 REMOTE OPERATION
85
5.5.3.2 SCPI STATUS REPORTING (continued)
The STATus:OPERation and STATus:QUEStionable registers provide information about the present mode
of operation.
Transition of a CONDition bit to the true state causes the EVENt bit to be set true.
Unmasked ENABle bits allow an EVENt bit to be reported in the summary bit for that EVENt register
in the STATUS BYTE register.
Setting an ENABLe bit true, unmasks the corresponding EVENt bit.
Reading an EVENt register clears it.
All :STATUS registers are 16 bits (Figure 5.3).
The STATus:OPERation registers provide information about the present mode of operation.
NOTE: Most bits in the following :STATus registers are not applicable to the UPC but are shown for
reference and may be used for future product enhancements.
The PROGram running bit (14) in the :STATus:OPERation registers indicates a stored program
(PROGRAM# 1-99) is running.
:STATus:OPERation:CONDition?
enables events to be reported in the SOS bit in the STB
:STATus:OPERation:ENABle?
STAT:OPER:ENABLE register query
The STATUS:QUESTIONABLE registers provide information about errors and questionable measurements.
NOTE: All bits in the following :STATus registers are not applicable to the UPC but are shown for reference
and may be used for future product enhancements.
:STATus:QUEStionable:CONDition?
:STATus:QUEStionable:ENABle
enables events to be reported in the SQS bit in the STB
:STATus:QUEStionable:ENABle?
STAT:OPER:ENABLE register query
:STATus:QUEStionable:EVENt?
