Panasonic 140 - Unit Dimensional Drawings

51
Appendix Heat Pump Chiller 140-210
Dimensions
2210
2856
48
171
559
1100
Ø2"1/2
2295 (140-150)
2321 (170-190-210)
2804
2148
1145152
1249
Ø17
1145152
1249
ECOi-W 140 to 210 without pump
Water inlet
Water outlet
