Panasonic 140 - Refrigerant Circuit Diagram

56
Appendix Heat Pump Chiller 140-210
Refrigerant circuit diagram
M1-1
M1-2
M2-1
M2-2
circuit 1
circuit 1
circuit 2
circuit 2
Compressors 1
Compressors 2
Compressors 1
Compressors 2
RV1
RV2
circuit 1
circuit 2
Cycle reversing valve
OFA/B
OFC/D
circuit 1
circuit 2
Outdoor fans motor
3-1
3-2
circuit 1
circuit 2
Air condenser
4-1
4-2
circuit 1
circuit 2
Filter drier
5-1
5-2
circuit 1
circuit 2
Sight glass
6-1
6-2
circuit 1
circuit 2
Electronic expansion valve
7-1
7-2
circuit 1
circuit 2
liquid receiver
8
Plate heat exchanger
Pressure tapping point 5/16''
FPC1
FPC2
circuit 1
circuit 2
High pressure transducer
HP1
HP2
circuit 1
circuit 2
High pressure switch (active 42 bar)
CDT1
CDT2
circuit 1
circuit 2
Discharge temperature sensor
FPE1
FPE2
circuit 1
circuit 2
Low pressure transducer
CST1
CST2
circuit 1
circuit 2
Suction temperature sensor
OCT1
OCT2
circuit 1
circuit 2
Condenser outdoor temperature
sensor
OAT
Outdoor air temperature sensor
