SECTION 400 (Version 3.0)
Issue 1 January 1990
DBS
FF-1 System mode
FFl-2#-1P20#-(0 or l-9)#
Application interface card assignment
This specifies the extension card slot number for
the API card to be used.
Assign this only when using the optional software.
O#:No API card assianed
1B:Extension card slot 1 is API card
2P: Extension card slot 2 is API card
3#: Extension card slot 3 is API card
48: Extension card slot 4 is API
card
f#:Extension card slot 5 is API card
6B:Extension card slot 6 isAPI card
ir#:Extension card slot 7 is API card
8#:Extension card slot 8 isAPI card
9#: Extension card slot 9 is API card
FFl-2#-l#-21#-(0 or l-9)#
Voice mail busy tone mode
This specifies if the DBS will send busy tone or
silence to the voice mail ports after an internal
conversation has ended.
##:Silence to voice mail- -*i Wr
a#:085 internal busv tone to voice mail
FFl-2#-2#-lk(0 or 1)s
Parity check
This is for aligning the data protocol specifications
between the machines when connecting
an
SlvlDR
printer to the system
or
carrying out remote
maintenance through the telephone circuit, for
example. Here it is specified whether to check for
the occurrence of errors during the
communication of data. The method of checking
involves adding up the data sent and determining
whetherthis constitutes an odd or even value. This
is referred to as a parity check
FFl-2#-2#-2#-(0 or l)#
Even/odd number parity
The mode of the parity check for the
communication data is set
09: Odd number parity
1 R: Even number oarity
FFl-2#- 2#-38-(1- 4)i
Data
transmission
speed (baud rate)
The baud
rate
for data transmission is set between
300 bps and 9600 bps, However, whatever the
setting may be usually, it is 300 bps when carrying
out remote maintenance through the telephone
FFl-2#-2#-4#-(l-3)#
Stop bit length
The length of the stop bit for transmitted data is
set
l#: 1 bit
28: 1.5 bits (Less than 90 port system only)
3%: 2 bits
FFl-2+2#-5#-(1- 4)#
Data length
The length of the transmitted data is set between
5 and 8 bi%.
18: 5 bits (Less than 90 port system only)
2%: 6 bits (Lessthan 90 port system only)
3#: 7 bits
4#: 8 bits
OR: No oaritv check
1 #: Parity check
-15
