CBS
FF-1 System mode
SECTION 400 (Version 3.0)
Issue 1 January 1990
FEI-2#-2#-6#-(0 or l)#
SMDR printing mode
1 (Outgoing/ Incoming)
This is for specifying whether to have the contents
recorded with the SMDR printer when making
outside calls only, or to have the contents when
answering incoming calls printed in addition to
the former.
OC: SMDR printing the outgoing calls only
1 f: SMDR orintina incomina and outaoina calls
NoterFor the SMDR printer to operate, as we// as
specifying printing in the system program it is
necessary to set the following from the
attendant’s phone.
k C,
iO~O~-~#~-~9l-~Ol-~On/O~ Bus data print mode
.$j
lOn/Off7-l#~-[9~-[l~-[OnfO~ Bus data resist mode
iOn/O~-~#l-[9~-[2~-[Onf OW Bus data accumuia te
? .Ci’
,. -+ [OnlOfn-~#~-i9~-~~-~On/O~ SMDR printout
FFl-2#-2#-7#-(0 or l)#
SMDR printing mode 2
(Long /Local)
This is for specifying whetherto have the contents
recorded with the SMDR printer when making toll
calls only, or to have the contents when making
local calls printed in addition to the former.
O#: SMDR priming the long distance calls only
l#: SMDR orintina all outaoina calls
Note 7: me long distance calls is as follows.
(N =2-s, P = 0.l.X = O-9)
Non + I Area NPX-NNX-XxXx
+ 1 Area I-NPX-NNX-XxXx
NPX is the area number, NNX the o ffke
number. and XXXX the phone number.
If the dialing starts with I or 0, it is deemed to
be a long distance calls.
FFl-2#-2#-8#-(0 or 1)#
SMDR printing mode 3 (Title)
It is specified whether to include titles such as
“TIME’, ‘DURAT’ and ‘CO#- on the top line for
making the data easy to read off, or to have the
data only when using the SMDR printer.
If there are titles, they are printed every 60 lines.
O#: SMDR orintina of communication data only
l#: SMDR printing of data titles in addition to
communication data
FFl-2#-2#-9#-(0 or l)#
Program data dump mode (X on/X off)
This is to specify whether or not to control the X
on/X off code should the data buffer overflow
when connecting the data terminal for carrying
out maintenance to the RS-232C interface for
connecting the SMDR
0#: X on/X off no control
lt: X on/x off controlled
FFl-2#-3#-1#-(0 - 999 or O* - 99*)#
PBX Dial 1
The access numbers are set for when using the PBX
circuit on the premises for as the systems outside
lines, or for connecting from a WAIT line, etc. to a
line of a telephone central office.
This setting is used for determining the dialing
when there are call restrictions for TRS, etc. In
addition, “*- can be stored as the wild card setting
here.
When 7 * is set, for example, 70 to 79 are taken as
PBX dialing. To clear the stored data, press
[CONF] key.
(0
- 9.00 - 99,000- 999 or 0’ - 9*, OO* - gg*)#:
Access numbers
Note :
To store wild card(*), use FF7 1 instead of
* key.
-16
