OUTPUT SETUP
Note: Items marked  will not function when OUTPUT BIT item is set to “4:2:2 10bit”.
Menu item
Description
Value (Factory default setting underlined)
OUTPUT SEL
Select video and audio
output.
HDMI / SDI / SDI+AV
RESOLUTION
Set resolution of output
video signal.
SYSTEM /1080p /1080i /DOWN CONV.
The type of signal available on the
output varies and will depend on REC
format setting.
See P. 61 for the details.
SDI REMOTE
Inserts the REC/PAUSE
trigger signal on SDI OUT.
This allows the camera to
control REC/PAUSE
functions of external
recorder via SDI OUT signal.
ON / OFF
REMOTE REC LINK
Set the way to control the
remote REC/PAUSE of an
external recorder.
ON: Remote REC/PAUSE can be
performed with the REC button on the
AG-DVX200.
OFF: Remote REC/PAUSE can be
performed with the user assignable
buttons (AUTO REC function) on the
AG-DVX200.
SDI EDH
EDH signal is embedded in
the SDI stream.
Enabled in 480i or 576i
mode only.
ON / OFF
SDI AUDIO GAIN
CHG
Set the audio gain of SDI
embedded audio signal.
0dB / -6dB / -12dB
 DOWN CONV.
Set the display mode of a
down converted image.
SIDE CROP / LETTERBOX /
SQUEEZE
HDMI UHD
OUTPUT LIMIT
Set the frame rate limit of
HDMI OUT while in
UHD 2160/59.94p 150M and
UHD 2160/50.00p 150M
record modes.
System freq = 59.94Hz
59.94p: Output in 2160/59.94p
29.97p: Output in 2160/29.97p
System freq = 50.00Hz
50.00p: Output in 2160/50.00p
25.00p: Output in 2160/25.00p
HDMI TC OUTPUT
Insert timecode signal on
HDMI OUT.
ON / OFF
VOLUME
Headphone volume
adjustments can be made
with the built-in jog dial.
ON / OFF
TEST TONE
Set the test tone level.
OFF / LEVEL1 (loud) / LEVEL2 (low)
VIDEO SETUP
Set the pedestal setup level.
Enabled in 480i mode only.
0% / 7.5%A
LCD/EVF OUTPUT
Set the way to use the LCD
and EVF monitors.
AUTO / LCD / EVF
