Panasonic CZ-KPY3A series Service Manual

1-11
1
Single-Type
1-1. Unit Specifi cations
PE1
1. 4-Way Cassette Type S-71PU1E5A / U-71PE1E5A
INDOOR MODEL S-71PU1E5A
PANEL MODEL CZ-KPU21 -
OUTDOOR MODEL U-71PE1E5A
Branch pipe MODEL -
PERFORMANCE TEST CONDITION ISO5151 / EN14511 / EN14825 / EN12102
POWER SUPPLY
ø, Hz 1ø 50Hz 1ø 50Hz
V 220 230 240 220 230 240 Min Max
C
O
O
L
I
N
G
CAPACITY
kW 7.1 7.1 7.1 2.5 8.0
BTU/h 24200 24200 24200 8500 27300
CURRENT A 0.36 0.33 0.32 8.40 8.10 7.90 - -
INPUT POWER
W 40 40 40 1.760k 1.760k 1.760k - -
TOTAL W - 1.800k 1.800k 1.800k 450 2.650k
ANNUAL CONSUMPTION TOTAL kWh
*
4 - - 900 - - -
EER/EER CLASS
TOTAL(W/W)
*
5/("A"~"G") - - - 3.94 3.94 / A 3.94 5.56 3.02
Erp
*
6
Pdsign kW - - - - 7.1 -
SEER (W/W) - - - - 7.4 -
Annual consumption kWh - - - - 336 -
Class - - - - A++ -
POWER FACTOR % - - - 95 94 93 - -
NOISE INDOOR
(H/M/L)
dB-A 37/31/28
Power Level dB 54/48/45
NOISE OUTDOOR
(H/L)
dB-A 48/-
Power Level dB 65/-
H
E
A
T
I
N
G
CAPACITY
kW 8.0 8.0 8.0 2.0 9.0
BTU/h 27300 27300 27300 6800 30700
CURRENT A 0.35 0.32 0.31 9.30 9.00 8.70 - -
INPUT POWER
W 40 40 40 1.960k 1.960k 1.960k - -
TOTAL W - 2.000k 2.000k 2.000k 400 2.900k
COP/COP CLASS
TOTAL(W/W)
*
5/("A"~"G") - - - 4.00 4.00 / A 4.00 5.00 3.10
Erp
*
6
Pdsign kW - - - - 7.1 -
Tbivalen °C - - - - -9 -
SCOP (W/W) - - - - 4.1 -
Annual consumption kWh - - - - 2424 -
Class - - - - A+ -
POWER FACTOR % - - - 96 95 94 - -
NOISE INDOOR
(H/M/L)
dB-A 37/31/28 - ⁄ ⁄
Power Level dB 54/48/45 -
NOISE OUTDOOR
(H/L)
dB-A - 50/- ⁄ ⁄
Power Level dB - 67/-
EXTRA LOW TEMP Total CAPACITY(kW)/INPUT POWER(W)/COP -
MAX CURRENT(A)/MAX INPUT POWER(W) 0.36/40 0.33/40 0.32/40 18.0/3.800k 18.0/3.930k 18.0/4.060k ⁄
STARTING CURRENT(A)/COMP OUTPUT(W) - - - 9.30/2.0k 9.00/2.0k 8.70/2.0k⁄
NETWORK IMPEDANCE (ΩMAX.) - -
FM OUTPUT (W) 60 90 ⁄
MOISTURE REMOVAL VOLUME L/h(Pt/h) 4.2 (8.8) -
External static pressure
Pa -
I/D AIR
FLOW
COOL m
3
/min (ft
3
/min) 22/17/14 (777/600/494)
HEAT m
3
/min (ft
3
/min) 22/17/14 (777/600/494)
O/D AIR
FLOW
COOL m
3
/min (ft
3
/min) 60 (2119)
HEAT m
3
/min (ft
3
/min) 60 (2119)
REFRIGERANT TYPE, AMOUNT
g
(oz) R410A 2.35k (82.9) /
P
R
O
D
I
M
HEIGHT : H mm(inch) 256 (10-3/32) 996 (39-7/32) /
WIDTH : W mm(inch) 840 (33-3/32) 940 (37-1/32) /
DEPTH : D mm(inch) 840 (33-3/32) 340 (13-13/32) /
P
A
C
D
I
M
HEIGHT : H mm 298 1136 /
WIDTH : W mm 929 1055 /
DEPTH : D mm 929 485 /
MASS
(NET) k
g
(lb) 24 (53) 69 (152) /
(GROSS) k
g
(lb) 30 (67) 77 (170) /
LAYERS LIMIT (actually) 11 (12) 2 (3)
Operation
Condition
Cool (DBT) 18°C ~ 32°C -15°C ~ 46°C
Heat (DBT) 16°C ~ 30°C -20°C ~ 24°C
P
I
P
I
N
G
PIPE DIAMETER mm (inch) (Liquid)ø9.52(3/8) (Gas)ø15.88(5/8) (Liquid)ø9.52(3/8) (Gas)ø15.88(5/8)
CONNECT METHOD, STD LENGTH m (ft) fl ared type, 5.0(16.4) fl ared type, 5.0(16.4)
PIPE LENGTH RANGE m (ft) 5 ~ 50 (16.4 ~ 164.0) ~ ~
I/D&O/D HEIGHT DIFFERENCE m (ft) 15 (OD located lower) / 30 (OD located higher) (49.2/98.4)
ADD GAS AMOUNT
g
/m (oz/ft) 50 (0.538)
PIPE LENGTH FOR ADDITIONAL GAS m (ft) 30 (98.4)
*1
:
In case it is necessary to indicate the air fl ow volume in (l/s), the value in (m
3
/min.) shall be multiplied by 16.7 and rounded down the decimal point.
*2
:
If the EUROVENT Certifi ed models can be operated under the “extra-low” temperature condition, -7°C dry bulb and -8°C wet-bulb temperatures with rated voltage
230 V shall be used.
*3
:
Network Impedance shall be applicable for EUROPE and CHINA models.
*4
:
The annual consumption is calculated by multiplying the input power at 230 V (400 V) by an average of 500 hours per year in cooling mode.
*5
:
EER and COP classification is at 230 V (400 V) only in accordance with EU directive 2002/31/EC.
*6
:
SEER and SCOP classification is at 230V(400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season,
Other fiche data indicates in an attached sheet.
