Panasonic CZ-KPY3A series Service Manual

1-12
1
Simultaneous (Twin) -Type
1-1. Unit Specifi cations
PE1
1. 4-Way Cassette Type S-71PU1E5A×2 / U-140PE1E5A
*1
:
In case it is necessary to indicate the air fl ow volume in (l/s), the value in (m
3
/min.) shall be multiplied by 16.7 and rounded down the decimal point.
*2
:
If the EUROVENT Certifi ed models can be operated under the “extra-low” temperature condition, -7°C dry bulb and -8°C wet-bulb temperatures with rated voltage
230 V shall be used.
*3
:
Network Impedance shall be applicable for EUROPE and CHINA models.
*4
:
The annual consumption is calculated by multiplying the input power at 230 V (400 V) by an average of 500 hours per year in cooling mode.
*5
:
EER and COP classification is at 230 V (400 V) only in accordance with EU directive 2002/31/EC.
*6
:
SEER and SCOP classification is at 230V(400V) only in accordance with EN-14825. For heating, SCOP indicates the value of only Average heating season,
Other fiche data indicates in an attached sheet.
INDOOR MODEL S-71PU1E5A×2
PANEL MODEL CZ-KPU21×2 -
OUTDOOR MODEL U-140PE1E5A
Branch pipe MODEL CZ-P155BK1
PERFORMANCE TEST CONDITION ISO5151 / EN14511 / EN12102
POWER SUPPLY
ø, Hz 1ø 50Hz 1ø 50Hz
V 220 230 240 220 230 240 Min Max
C
O
O
L
I
N
G
CAPACITY
kW 14.0 14.0 14.0 3.3 15.5
BTU/h 47800 47800 47800 11300 52900
CURRENT A 0.36×2 0.33×2 0.32×2 19.8 19.2 18.6 - -
INPUT POWER
W 40×2 40×2 40×2 4.230k 4.230k 4.230k - -
TOTAL W - 4.310k 4.310k 4.310k 840 6.000k
ANNUAL CONSUMPTION TOTAL kWh
*
4 - - 2155 - - -
EER/EER CLASS
TOTAL(W/W)
*
5/("A"~"G") - - - 3.25 3.25 / A 3.25 3.93 2.58
Erp
*
6
Pdsign kW ------
SEER (W/W) ------
Annual consumption kWh------
Class ------
POWER FACTOR % - - - 97 96 95 - -
NOISE INDOOR
(H/M/L)
dB-A 37/31/28
Power Level dB 54/48/45
NOISE OUTDOOR
(H/L)
dB-A 54/-
Power Level dB 71/-
H
E
A
T
I
N
G
CAPACITY
kW 16.0 16.0 16.0 4.1 18.0
BTU/h 54600 54600 54600 14000 61400
CURRENT A 0.35×2 0.32×2 0.31×2 19.9 19.3 18.7 - -
INPUT POWER
W 40×2 40×2 40×2 4.250k 4.250k 4.250k - -
TOTAL W - 4.330k 4.330k 4.330k 900 5.900k
COP/COP CLASS
TOTAL(W/W)
*
5/("A"~"G") - - - 3.70 3.70 / A 3.70 4.56 3.05
Erp
*
6
Pdsign kW --------
Tbivalen °C ------
SCOP (W/W) ------
Annual consumption kWh------
Class ------
POWER FACTOR % - - - 97 96 95 - -
NOISE INDOOR
(H/M/L)
dB-A 37/31/28 - ⁄ ⁄
Power Level dB 54/48/45 -
NOISE OUTDOOR
(H/L)
dB-A - 55/- ⁄ ⁄
Power Level dB - 71/-
EXTRA LOW TEMP Total CAPACITY(kW)/INPUT POWER(W)/COP -
MAX CURRENT(A)/MAX INPUT POWER(W) 0.36×2/40×2 0.33×2/40×2 0.32×2/40×2 30.0/6.450k 30.0/6.650k 30.0/6.850k ⁄
STARTING CURRENT(A)/COMP OUTPUT(W) - - - 19.9/3.0k 19.3/3.0k 18.7/3.0k⁄
NETWORK IMPEDANCE (ΩMAX.) - -
FM OUTPUT (W) 60×2 90x2 ⁄
MOISTURE REMOVAL VOLUME L/h(Pt/h) 9.0 (4.5×2) (18.9) -
External static pressure
Pa -
I/D AIR
FLOW
COOL m
3
/min (ft
3
/min) [22/17/14 (777/600/494)]×2
HEAT m
3
/min (ft
3
/min) [22/17/14 (777/600/494)]×2
O/D AIR
FLOW
COOL m
3
/min (ft
3
/min) 135 (4767)
HEAT m
3
/min (ft
3
/min) 120 (4238)
REFRIGERANT TYPE, AMOUNT
g
(oz) R410A 3.40k (119.9) /
P
R
O
D
I
M
HEIGHT : H mm(inch) 256 (10-3/32) 1416 (55-3/4) /
WIDTH : W mm(inch) 840 (33-3/32) 940 (37-1/32) /
DEPTH : D mm(inch) 840 (33-3/32) 340 (13-13/32) /
P
A
C
D
I
M
HEIGHT : H mm 298 1556 /
WIDTH : W mm 929 1055 /
DEPTH : D mm 929 485 /
MASS
(NET) k
g
(lb) 24 (53) 98 (216) /
(GROSS) k
g
(lb) 30 (67) 108 (238) /
LAYERS LIMIT (actually) 11 (12) 1 (2)
Operation
Condition
Cool (DBT) 18°C ~ 32°C -15°C ~ 46°C
Heat (DBT) 16°C ~ 30°C -20°C ~ 24°C
P
I
P
I
N
G
PIPE DIAMETER mm (inch) (Liquid)ø9.52(3/8) (Gas)ø15.88(5/8) (Liquid)ø9.52(3/8) (Gas)ø15.88(5/8)
CONNECT METHOD, STD LENGTH m (ft) fl ared type, 5.0(16.4) fl ared type, 5.0(16.4)
PIPE LENGTH RANGE m (ft) 5 ~ 75 (16.4 ~ 246.1) ~ ~
I/D&O/D HEIGHT DIFFERENCE m (ft) 15 (OD located lower) / 30(OD located higher) (49.2/98.4)
ADD GAS AMOUNT
g
/m (oz/ft) 50 (0.538)
PIPE LENGTH FOR ADDITIONAL GAS m (ft) 30 (98.4)
