1-245
1
1-6. Noise Criterion Curves
(B) Outdoor Unit
MODEL
SOUND LEVEL
CONDITION
: U-100PE1E5A, U-100PE1E8A
: Heating 52 dB(A)
: 1 m in front at height of 1.5 m
MODEL
SOUND LEVEL
CONDITION
: U-100PE1E5A, U-100PE1E8A
: Cooling 52 dB(A)
: 1 m in front at height of 1.5 m
Octave Band Level (dB)
*0dB = 0.0002 Ī¼bar
Octave Band Level (dB)
*0dB = 0.0002 Ī¼bar
Octave Band Level (dB)
*0dB = 0.0002 Ī¼bar
Octave Band Level (dB)
*0dB = 0.0002 Ī¼bar
Frequency at center of sound pressure band (Hz)
Frequency at center of sound pressure band (Hz)
Frequency at center of sound pressure band (Hz)
Frequency at center of sound pressure band (Hz)
10
20
30
40
50
60
NC-60
NC-50
NC-40
NC-30
NC-20
10
20
30
40
50
60
63 125 250 500 1000 2000 4000 8000 63 125 250 500 1000 2000 4000 8000
NC-40
NC-60
NC-50
NC-30
NC-20
MODEL
SOUND LEVEL
CONDITION
: U-125PE1E5A, U-125PE1E8A
: Heating 53 dB(A)
: 1 m in front at height of 1.5 m
MODEL
SOUND LEVEL
CONDITION
: U-125PE1E5A,U-125PE1E8A
: Cooling 53 dB(A)
: 1 m in front at height of 1.5 m
10
20
30
40
50
60
NC-40
NC-50
NC-30
NC-20
NC-60
10
20
30
40
50
60
NC-40
NC-60
NC-50
NC-30
NC-20
Approximate
minimum
audible limit
for continuous
noise
Approximate
minimum
audible limit
for continuous
noise
Approximate
minimum
audible limit
for continuous
noise
Approximate
minimum
audible limit
for continuous
noise
Heating
Cooling
Heating
Cooling
SOURCE
1 phase model
SOURCE
: 220-230-240V, 1 phase, 50Hz1 phase model
: 380-400-415V, 3 phase, 50Hz3 phase model
: 220-230-240V, 1 phase, 50Hz
3 phase model : 380-400-415V, 3 phase, 50Hz
SOURCE
1 phase model
SOURCE
: 220-230-240V, 1 phase, 50Hz1 phase model
: 380-400-415V, 3 phase, 50Hz3 phase model
: 220-230-240V, 1 phase, 50Hz
3 phase model : 380-400-415V, 3 phase, 50Hz
63 125 250 500 1000 2000 4000 8000 63 125 250 500 1000 2000 4000 8000
