Panasonic CZ-KPY3A series Service Manual

1-253
1
Heating : Distribution of wind velocity
Heating : Distribution of temperature
Cooling : Distribution of wind velocity
Cooling : Distribution of temperature
Vertical air flow distance (m) Vertical air flow distance (m) Vertical air flow distance (m) Vertical air flow distance (m)
0
1
2
3
0
1
2
3
24°C
26°C
22°C
0
1
2
3
0
1
2
3
1.5m/s
1.0m/s
0.5m/s
0.3m/s
0
1
2
3
0
1
2
3
5 532321 104 4
0
1
2
3
0
1
2
3
1.5m/s
1.0m/s
0.5m/s
0.3m/s
4-Way Cassette (Type U1)
S-100PU1E5A / 125PU1E5A / 140PU1E5A
Horizontal air flow distance (m)
Horizontal air flow distance (m)
Horizontal air flow distance(m)
Horizontal air flow distance (m)
(Strong wind : Discharge angle approx.65°) (Room temperature approx.20°C)
5 532321 104 4
33°C
27°C
24°C
30°C
(Strong wind : Discharge angle approx.65°) (Room temperature approx.20°C)
(Strong wind : Discharge angle approx.30°) (Room temperature approx.27°C)
5 532321 104 4
5 532321 104 4
20°C
(Strong wind : Discharge angle approx.30°) (Room temperature approx.27°C)
