1
1-340
CZ-P3HPC2
Unit : mm
CZ-P3HPC2 (for simultaneous Triple)
Liquid distribution joint for liquid tube Gas distribution joint for gas tube
Dowel pin
position
(3 locations)
Liquid-tube side tube connector Gas-tube side tube connector
Thermal insulation for liquid distribution joints Thermal insulation for gas distribution joints
Gas-tube side tube connector
100 35
80
80
(295)
Ćø9.52Ćø9.52Ćø9.52
1
2
1
2
3
4
5
6
BCUP-3
100 80 80
300
100
Ćø12.7
Ćø25.4
Ćø15.88Ćø15.88
Ćø15.88
1
1
Ćø9.52 Ćø12.7
Ćø9.52
Ćø6.35
3
1
Ćø12.7
Ćø15.88
Ćø19.05
Ćø25.4
3
1
1 1
1
Ćø15.88
Ćø19.05
Ćø25.4
Ćø28.58
2
SM830231-02īSingleī꬧å·.indbīīī340SM830231-02īSingleī꬧å·.indbīīī340 2014/09/19īīī13:21:532014/09/19īīī13:21:53
