(Low Silhouette Ducted)
Part Name Figure Qāty Remarks
Washer
8
For suspending indoor
unit from ceiling
Flare insulator
2 For gas and liquid tubes
Insulating
tape
2
For gas and liquid tubes
flare nuts
Drain
insulator
1 For drain hose joint
Hose band
1 For securing drain hose
Packing
1
For drain hose joint
(hard material)
Packing
1
For drain hose joint
(soft material)
Drain hose
1
Operating
Instructions
1 A5-size
Installation
Instructions
1 Included this instructions
Short-circuit
connection
1
For high static pressure
(Located on the back of
the electrical component
box lid. )
Use M10 for suspension bolts.
Suspension bolts and nuts are field supply.
