1
1-438
Outdoor air intake temp(Ā°C D.B.)
Model
Power
Source
Ambient
Return
Air
25Ā°C 30Ā°C 35Ā°C 40Ā°C 43Ā°C
DB WB TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT
S-100PN1E5A
U-100PEY1E5
(U-100PEY1E8)
220V
230V
240V
50Hz
1phase
(3phase)
23
16 11.1 8.9 3.45 10.6 8.5 3.72 10.1 8.2 3.99 8.5 7.2 3.79 6.1 5.6 2.61
19 11.9 6.7 3.60 11.3 6.3 3.88 10.7 6.1 4.16 9.1 5.4 3.95 6.5 4.0 2.72
22 13.0 4.5 3.73 12.4 4.3 4.01 11.8 4.0 4.30 10.0 3.5 4.09 7.2 2.5 2.82
25
16 11.5 10.7 3.51 11.0 10.2 3.78 10.4 9.8 4.06 8.8 8.7 3.85 6.3 6.3 2.66
19 12.3 8.3 3.66 11.7 7.9 3.95 11.1 7.7 4.23 9.4 6.8 4.02 6.8 5.3 2.77
22 13.5 6.2 3.79 12.8 5.9 4.08 12.2 5.6 4.38 10.3 4.8 4.16 7.4 3.6 2.87
27
16 11.9 11.9 3.57 11.3 11.3 3.85 10.8 10.8 4.12 9.1 9.1 3.92 6.6 6.6 2.70
19 12.7 10.2 3.72 12.1 9.7 4.01 11.5 9.3 4.30 9.8 8.4 4.09 7.0 6.5 2.82
22 13.9 7.9 3.85 13.3 7.6 4.15 12.6 7.2 4.45 10.7 6.3 4.23 7.7 4.9 2.91
29
16 12.1 12.1 3.58 11.5 11.5 3.86 10.9 10.9 4.13 9.3 9.3 3.93 6.7 6.7 2.71
19 12.9 11.9 3.73 12.3 11.3 4.02 11.7 10.9 4.31 9.9 9.8 4.10 7.1 7.1 2.82
22 14.1 9.5 3.86 13.5 9.1 4.16 12.8 8.8 4.46 10.9 7.8 4.24 7.8 6.1 2.92
32
16 12.3 12.3 3.59 11.7 11.7 3.86 11.1 11.1 4.14 9.4 9.4 3.94 6.8 6.8 2.71
19 13.1 12.1 3.74 12.5 11.5 4.03 11.8 11.0 4.32 10.1 10.0 4.11 7.2 7.2 2.83
22 14.3 9.6 3.87 13.7 9.2 4.17 13.0 8.9 4.47 11.0 7.9 4.25 7.9 6.1 2.93
S-125PN1E5A
U-125PEY1E5
(U-125PEY1E8)
220V
230V
240V
50Hz
1phase
(3phase)
23
16 12.5 9.6 4.18 12.2 9.3 4.50 11.8 9.0 4.82 9.5 7.7 4.58 7.2 6.2 3.16
19 13.4 7.3 4.36 13.0 7.1 4.69 12.6 6.9 5.03 10.2 5.8 4.78 7.7 4.6 3.29
22 14.7 5.0 4.51 14.3 4.9 4.86 13.8 4.7 5.20 11.1 3.8 4.95 8.4 2.9 3.41
25
16 13.0 11.3 4.25 12.6 11.1 4.57 12.2 10.8 4.90 9.9 9.3 4.66 7.4 7.2 3.21
19 13.8 8.9 4.43 13.5 8.8 4.77 13.1 8.6 5.12 10.5 7.2 4.86 8.0 5.8 3.35
22 15.2 6.7 4.58 14.8 6.6 4.94 14.3 6.3 5.29 11.5 5.2 5.03 8.7 4.1 3.47
27
16 13.4 13.2 4.32 13.0 12.9 4.65 12.6 12.6 4.99 10.2 10.2 4.74 7.7 7.7 3.26
19 14.3 10.8 4.50 13.9 10.5 4.85 13.5 10.3 5.20 10.9 8.7 4.94 8.2 7.1 3.41
22 15.7 8.6 4.66 15.3 8.3 5.02 14.8 8.1 5.38 11.9 6.7 5.11 9.0 5.4 3.52
29
16 13.6 13.6 4.33 13.2 13.2 4.66 12.8 12.8 5.00 10.3 10.3 4.75 7.8 7.8 3.27
19 14.5 12.5 4.51 14.1 12.1 4.86 13.7 11.9 5.21 11.1 10.2 4.95 8.3 8.0 3.41
22 15.9 10.2 4.67 15.5 9.9 5.03 15.0 9.7 5.39 12.1 8.1 5.12 9.1 6.6 3.53
32
16 13.8 13.8 4.34 13.4 13.4 4.67 13.0 13.0 5.01 10.5 10.5 4.76 7.9 7.9 3.28
19 14.7 12.6 4.52 14.3 12.3 4.88 13.9 12.1 5.23 11.2 10.3 4.97 8.5 8.2 3.42
22 16.2 10.4 4.68 15.7 10.0 5.04 15.2 9.9 5.41 12.3 8.3 5.14 9.3 6.8 3.54
S-140PN1E5A
U-140PEY1E8
220V
230V
240V
50Hz
3phase
23
16 14.1 10.4 4.87 14.1 10.5 5.23 13.6 10.1 5.56 12.6 9.8 5.79 9.2 7.7 4.73
19 15.1 8.0 5.08 15.1 8.1 5.46 14.5 7.8 5.80 13.5 7.4 6.04 9.8 5.6 4.93
22 16.5 5.7 5.25 16.5 5.6 5.64 15.9 5.5 6.00 14.8 5.1 6.25 10.8 3.7 5.10
25
16 14.6 12.3 4.95 14.6 12.4 5.32 14.0 11.9 5.66 13.1 11.7 5.88 9.5 9.0 4.81
19 15.6 9.8 5.16 15.6 9.9 5.55 15.0 9.5 5.90 13.9 9.2 6.14 10.2 7.2 5.02
22 17.1 7.4 5.34 17.1 7.5 5.74 16.4 7.1 6.11 15.3 6.8 6.35 11.2 5.2 5.19
27
16 15.1 14.2 5.03 15.1 14.3 5.41 14.5 13.9 5.75 13.5 13.5 5.98 9.9 9.9 4.89
19 16.1 11.7 5.25 16.1 11.8 5.64 15.5 11.4 6.00 14.4 11.1 6.24 10.5 8.7 5.10
22 17.7 9.3 5.43 17.7 9.4 5.83 17.0 9.0 6.21 15.8 8.7 6.46 11.5 6.7 5.28
29
16 15.3 15.3 5.05 15.3 15.3 5.42 14.7 14.7 5.77 13.7 13.7 6.00 10.0 10.0 4.90
19 16.4 13.5 5.26 16.4 13.5 5.65 15.7 13.1 6.01 14.6 12.9 6.26 10.7 10.1 5.11
22 17.9 11.1 5.44 17.9 11.2 5.85 17.2 10.8 6.22 16.0 10.5 6.47 11.7 8.2 5.29
32
16 15.5 15.5 5.06 15.5 15.5 5.43 14.9 14.9 5.78 13.9 13.9 6.01 10.2 10.2 4.91
19 16.6 13.7 5.28 16.6 13.7 5.67 16.0 13.4 6.03 14.8 13.0 6.27 10.9 10.3 5.13
22 18.2 11.3 5.46 18.2 11.4 5.86 17.5 11.0 6.24 16.3 10.7 6.49 11.9 8.3 5.30
1-13. Capacity Table
1. Cooling Capacity Performance Data
ā¢
Combination of Single Unit
Ducted Type
TC :Cooling Capacity
SHC :Sensible Heat Capacity
IPT :Cooling Power Consumption
unit : kW
