Panasonic CZ-KPY3A series Service Manual

4-40
4
SM830211-05PAC-i.indb22 2012/10/1021:13:46
LED for
EEPROM
memory IC
(D330)
CHK
D302
(LED1)
D303
(LED2)
CN-OPT1
CN-OPT2
Outdoor air
temp
(CN-TO)
Comp
discharge
temp
(CN-TD)
TEST
JP001
TERMINAL
POWER LED
(D514)
EEPROM memory IC
(IC18)
Inlet
temperature
sensor in heat
exchanger
(CN-C1)
Intermediate
temperature
sensor in heat
exchanger
(CN-C2)
MOV plug
(CN-MOV1)
EMG plug
(CN-EMG)
High-pressure
switch plug
(CN-63PH)
OC plug
(CN-OC)
STOP
CN-PRY2
CN-PRY1
MODE
A.ADD
RUN
PUMP DOWN
S002
S003
SILENT
(CN-SILENT)
Suction temp
(CN-TS)
RC plug
(CN-RC)
CR-PCB
A747247 (U-100PEY1E8, U-125PEY1E8)
SM830231-02Single欧州.indb40SM830231-02Single欧州.indb40 2014/09/0921:15:442014/09/0921:15:44
