5-66
5
Outdoor Unit Control PCB
CR-60PEY1E5 : bottom (U-60PEY1E5)
(for single-phase outdoor unit PCB)
NU PWVU
CR-71PEY1E5 : bottom (U-71PEY1E5)
(for single-phase outdoor unit PCB)
NU PWVU
A746846 : (U-100PEY1E5)
(for single-phase outdoor unit HIC PCB)
A746847 : (U-125PEY1E5)
(for single-phase outdoor unit HIC PCB)
UVW PNU
UVW PNU
Outdoor Unit Control HIC PCB
